CMI Aluminum Double Micro Pulley

$81.30

The CMI Aluminum Double Micro Pulley is a compact double pulley designed for rescue, hauling, and rigging systems. Purple anodized aluminum side plates, two 1.25 inch aluminum sheaves, Oilite bronze bushings, and an aluminum axle provide durable, smooth performance. The pulley accepts rope up to 1/2 inch, has a 7,000 lb minimum breaking strength, and a 1,400 lb working load limit.

In stock (can be backordered)

SKU: RP110D

The CMI RP110D Double Sheave Micro Pulley features purple anodized aluminum sideplates, two 1-1/4″ aluminum sheaves, bushing, and aluminum axle.

Specifications:

  • Sheave Diameter: 1.25" (2)
  • Max Rope Diameter: 1/2"
  • Body Material: Anodized Aluminum
  • Sheave Mechanics: Oilite Bronze Bushing
  • Sheave Material: Aluminum
  • MBS: 7,000 lbs
  • SWL: 1,400 lbs
  • Width: 1.625"
  • Height: 3.50"
  • Depth: 1.775" (sideplate to sideplate)

Specifications:

  • Sheave Diameter: 1.25″ (2)
  • Max Rope Diameter: 1/2″
  • Body Material: Anodized Aluminum
  • Sheave Mechanics: Oilite Bronze Bushing
  • Sheave Material: Aluminum
  • MBS: 7,000 lbs
  • SWL: 1,400 lbs
  • Width: 1.625″
  • Height: 3.50″
  • Depth: 1.775″ (sideplate to sideplate)
