Junkin’s Head Immobilizer is designed to secure a patient’s head and neck in place while attached to spineboard. The head immobilizer is vinyl coated and is both buoyant and waterproof. Additionally, the immobilizer can be left in place during X-rays.

Head immobilzer can be added to any backboard for excellent head restraint. Designed and recommended for immobilization only. Made in USA

Instructions - Attaching The Head Immobilizer To The Spine board

Make sure head immobilizer is taken apart. You should have 1 base plate, 2 head blocks and 2 head/chin straps. Place base plate against top of spine board with attached straps stretched out. The straps attached to the base plate loop over and then through the handle running the strap in-between the board and the base plate. The run strap through and over other handle and attach strap to Velcro on base plate. Repeat with 2nd strap. Attach retention strap at top of base plate by looping through center hole of spine board. Attach head blocks to Velcro and place head/chin straps over blocks and loop Velcro ends through D rings on base plate.

Securing the patient in the Head Immobilizer

Position the patient on the backboard so that their head is positioned in the middle of the base plate. Secure the patient on the backboard with restraining straps. Place the head blocks against each side of the patients head. When possible align the holes in the head blocks with the patient's ears so you can hear the patient. Loop each end of the forehead/chin straps through the D rings. Tighten as needed.
